3  Git and GitHub

Before we start: everybody make sure you have Git installed. Open a terminal and type:

git -v

If not installed follow the instruction in textbook.

Goal for the day: create a repository, push something to the repository, connect RStudio to GitHub, clone the class notes.

We want to avoid this:

Posted by rjkb041 on r/ProgrammerHumor

This is particularly true when more than one person is collaborating on editing the file. And even more important when there are multiple files, as there is in software development, and to some extend data analysis.

Git is a version control system that provides a systematic approach to keeping versions of files.

Posted on devrant.com/ by bhimanshukalra

But we have to learn some things:

From Meme Git Compilation by Lulu Ilmaknun Qurotaini
Note

I use < > to denote a placeholder. So if I say <filename> what you eventually type is the filename you want to use, without the < >

3.1 Why use Git and GitHub?

  1. Sharing.

  2. Collaborating.

  3. Version control.

We focus on the sharing aspects of Git and GitHub, but introduce some of the basics that permit you to collaborate and version control.

3.2 What is Git?

Art by: Allison Horst

3.3 What is GitHub?

Basically, it’s a service that hosts the remote repository (repo) on the web. This facilitates collaboration and sharing greatly.

There many other features such as

  • a recognition system: reward, badges and stars, for example.
  • hosting web pages, like the class notes for example.
  • forks and pull requests,
  • issue tracking
  • automation tools

It has been describes a social network for software developers.

The main tool behind GitHub, is Git.

Similar to how to how main tool behind RStudio, is R.

3.4 GitHub accounts

Once you have a GitHub account, you are ready to connect Git and RStudio to this account.

A first step is to let Git know who we are. This will make it easier to connect with GitHub. We start by opening a terminal window in RStudio (remember you can get one through Tools in the menu bar). Now we use the git config command to tell Git who we are. We will type the following two commands in our terminal window:

git config --global user.name "Your Name"
git config --global user.mail "your@email.com"

Consider adding a profile README.md. Instructions are here

Looks like this

3.5 Repositories

You are now ready to create a GitHub repository (repo). This will be your remote repo.

The general idea is that you will have at least two copies of your code: one on your computer and one on GitHub. If you add collaborators to this repo, then each will have a copy on their computer. The GitHub copy is usually considered the main (previously called master) copy that each collaborator syncs to. Git will help you keep all the different copies synced.

Let’s go make one on GitHub…

Then create a directory on your computer, this will be the local repo, and connect it to the Github repository.

First copy and paste the location of your git repository

It should look something like this:

https://github.com/your-username/your-repo-name.git
git init
git remote add origin <remote-url>

Now the two are connected.

3.6 Overview of Git

The main actions in Git are to:

  1. pull changes from the remote repo, in this case the GitHub repo
  2. add files, or as we say in the Git lingo stage files
  3. commit changes to the local repo
  4. push changes to the remote repo, in our case the GitHub repo

From Meme Git Compilation by Lulu Ilmaknun Qurotaini

3.6.1 The four areas of Git

3.6.2 Status

git status filename

3.6.3 Add

Use git add to move put file to staging area.

git add <filename>
git status <filename>

3.6.4 Commit

Use

git commit -m "must add comment"

to move all the added files to the local repository. This file is now tracked and a copy of this version is kept going forward… this is like adding V1 to your filename.

You can commit files directly without using add by explicitely writing the files at the end of the commit:

git commit -m "must add comment" <filename>

3.6.5 Push

To move to upstream repo we use

git push -u origin main

The -u flag sets the upstream, so in the future, you can simply use git push to push changes. So going forward we can just type:

git push

Here we need to be careful as if collaborating this will affect the work of others. It might also create a conflict.

3.6.6 Fetch

To update our local repository to the remote one we use

git fetch

3.6.7 Merge

Once we are sure this is good, we can merge with our local files

git merge

3.6.8 Pull

It is common to want to just skip the fetch step and just update everything. For this we use

git pull

3.6.9 Checkout

Posted by andortang on Nothing is Impossible! If you want to pull down a specific file you from the remote repo you can use:

git checkout filename

But if you have a newer version in your local repository this will create a conflict. If you are sure you want to get rid of your local copy you can remove and then checkout.

You can also use checkout to pull older version:

git checkout <commit-id> <filename>

You can get the commit-id either on the GitHub webpage or using

git log filename
Note

If you are asked for passwords when connecting or pushing things to you want to read this and avoid this. It will be impossible to use if you have to enter a password each time you push.

3.7 Branches

Git can be even more complex. We can have several branches. These are useful for working in parallel or testing stuff out that might not make the main repo.

Art by: Allison Horst

We wont go over this. But you should at least now these three commands

git remote -v
git brach

3.8 Clone

If you

git clone <repo-url>
pwd
mkdir git-example
cd git-example
git clone https://github.com/rairizarry/murders.git
cd murders

3.9 Using Git in RStudio

Go to file, new project, version control, and follow the instructions. Then notice the Git tab.

From Meme Git Compilation by Lulu Ilmaknun Qurotaini For more memes see Meme Git Compilation by Lulu Ilmaknun
